Read trigger files. More...
#include <ReadTriggers.h>
Public Member Functions | |
| bool | Clusterize (void) |
| Clusters triggers. | |
| double | GetClusterAmplitude (const int aclst) |
| Returns the peak Amplitude of cluster number aclst. | |
| double | GetClusterBandWidth (const int aclst) |
| Returns the bandwidth of cluster number aclst. | |
| double | GetClusterDuration (const int aclst) |
| Returns the duration of cluster number aclst. | |
| double | GetClusterFrequency (const int aclst) |
| Returns the peak frequency of cluster number aclst. | |
| double | GetClusterFrequencyEnd (const int aclst) |
| Returns the ending frequency of cluster number aclst. | |
| double | GetClusterFrequencyStart (const int aclst) |
| Returns the starting frequency of cluster number aclst. | |
| double | GetClusterMeanDuration (void) |
| Returns the mean duration of clusters. | |
| int | GetClusterNumber (const double atime) |
| Returns the cluster number of cluster overlapping time atime. | |
| double | GetClusterQ (const int aclst) |
| Returns the peak Q value of cluster number aclst. | |
| int | GetClusterSize (const int aclst) |
| Returns the size of cluster number aclst. | |
| double | GetClusterSNR (const int aclst) |
| Returns the peak SNR of cluster number aclst. | |
| int | GetClusterStatus (const int aclst) |
| Returns the status value of cluster number aclst. | |
| double | GetClusterTheta (const int aclst) |
| Returns the theta value of cluster number aclst. | |
| double | GetClusterTime (const int aclst) |
| Returns the peak time of cluster number aclst. | |
| double | GetClusterTimeEnd (const int aclst) |
| Returns the ending time of cluster number aclst. | |
| double | GetClusterTimeStart (const int aclst) |
| Returns the starting time of cluster number aclst. | |
| double | GetDeltaT (void) |
| Returns the clustering delta_t value. | |
| double | GetFrequencyMax (void) |
| Returns the maximum value of frequency in the trigger sample. | |
| double | GetFrequencyMin (void) |
| Returns the minimum value of frequency in the trigger sample. | |
| int | GetNcluster (void) |
| Returns the number of clusters. | |
| int | GetNCluster (void) |
| Returns the number of clusters. | |
| int | GetNtrig (void) |
| Returns the number of triggers. | |
| int | GetNTrig (void) |
| Returns the number of triggers. | |
| int | GetNTriggers (void) |
| Returns the number of triggers. | |
| int | GetNtriggers (void) |
| Returns the number of triggers. | |
| double | GetSNRMax (void) |
| Returns the maximum value of SNR in the trigger sample. | |
| double | GetSNRMin (void) |
| Returns the minimum value of SNR in the trigger sample. | |
| double | GetTimeMax (void) |
| Returns the maximum time value in the trigger sample. | |
| double | GetTimeMin (void) |
| Returns the minimum time value in the trigger sample. | |
| double | GetTriggerAmplitude (const int atrig) |
| Returns the amplitude of trigger number atrig. | |
| double | GetTriggerBandWidth (const int atrig) |
| Returns the bandwidth of trigger number atrig. | |
| double | GetTriggerDuration (const int atrig) |
| Returns the duration of trigger number atrig. | |
| string | GetTriggerFile (const double atime) |
| Returns the path to the file containing trigger time atime. | |
| string | GetTriggerFile (const int atrig) |
| Returns the path to the file containing trigger number atrig. | |
| double | GetTriggerFrequency (const int atrig) |
| Returns the frequency of trigger number atrig. | |
| double | GetTriggerFrequencyEnd (const int atrig) |
| Returns the ending frequency of trigger number atrig. | |
| double | GetTriggerFrequencyStart (const int atrig) |
| Returns the starting frequency of trigger number atrig. | |
| double | GetTriggerQ (const int atrig) |
| Returns the Q value of trigger number atrig. | |
| double | GetTriggerSNR (const int atrig) |
| Returns the SNR value of trigger number atrig. | |
| double | GetTriggerTime (const int atrig) |
| Returns the time of trigger number atrig. | |
| double | GetTriggerTimeEnd (const int atrig) |
| Returns the ending time of trigger number atrig. | |
| double | GetTriggerTimeStart (const int atrig) |
| Returns the starting time of trigger number atrig. | |
| bool | SetClusterBranchStatus (const char *bname, bool status=true) |
| Modifies the branch status of the cluster tree. | |
| bool | SetClusterSNRthr (const double asnrthr) |
| Sets a SNR threshold for clustering. | |
| bool | SetClusterStatus (const int aclst, const int anewstatus) |
| Sets a new cluster status value. | |
| bool | SetDeltaT (const double adeltat) |
| Sets a new clustering delta_t. | |
| bool | SetNewPattern (const string apattern) |
| Loads new trigger files. | |
| bool | SetTriggerBranchStatus (const char *bname, bool status=true) |
| Modifies the branch status of the triggers tree. | |
| bool | WriteClusters (TFile *atfile, const string adirectory="") |
| Writes clusters in a ROOT file. | |
Constructors and destructors | |
| ReadTriggers (const string apattern, const string adirectory="", const int averbose=0) | |
| Constructor of the ReadTriggers class. | |
| virtual | ~ReadTriggers (void) |
| Destructor of the ReadTriggers class. | |
Protected Attributes | |
| double | Camp |
| cluster peak Amplitude (TTree) | |
| double | Cdelta_t |
| time clustering delta_t (s) | |
| double | Cfend |
| cluster peak frequency end (TTree) | |
| Long64_t | Cfirstentry |
| cluster first trigger entry (TTree) | |
| double | Cfreq |
| cluster peak frequency (TTree) | |
| double | Cfstart |
| cluster peak frequency start (TTree) | |
| double | cl_snr_thr |
| SNR threshold for clustering. | |
| int * | cl_status |
| cluster status | |
| double | Cmeandur |
| cluster mean duration | |
| double | Cq |
| cluster peak Q (TTree) | |
| Long64_t | Csize |
| cluster size (TTree) | |
| double | Csnr |
| cluster peak SNR (TTree) | |
| double | Ctend |
| cluster peak time end (TTree) | |
| double | Ctime |
| cluster peak time (TTree) | |
| TTree * | Ctree |
| cluster parameter tree | |
| double | Ctstart |
| cluster peak time start (TTree) | |
| double | fFreqMax |
| max peak frequency | |
| double | fFreqMin |
| min peak frequency | |
| double | fSNRMax |
| max peak snr | |
| double | fSNRMin |
| min peak snr | |
| Long64_t * | offsets |
| tree offsets - DO NOT DELETE | |
| double | Tamp |
| trigger peak Amplitude (TTree) | |
| double | Tfend |
| trigger peak frequency end (TTree) | |
| double | Tfreq |
| trigger peak frequency (TTree) | |
| double | Tfstart |
| trigger peak frequency start (TTree) | |
| double | Tq |
| trigger peak Q (TTree) | |
| double | Tsnr |
| trigger peak SNR (TTree) | |
| double | Ttend |
| trigger peak time end (TTree) | |
| double | Ttime |
| trigger peak time (TTree) | |
| Chain * | Ttree |
| trigger parameter trees | |
| double | Ttstart |
| trigger peak time start (TTree) | |
Read trigger files.
This class was designed to read triggers stored in TTrees saved in ROOT files (following the GWOLLUM convention). This class provides many functions to access the trigger characteristics. Moreover it offers several algorithms to cluster triggers on the fly.
| ReadTriggers::ReadTriggers | ( | const string | apattern, | |
| const string | adirectory = "", |
|||
| const int | averbose = 0 | |||
| ) |
Constructor of the ReadTriggers class.
The trigger files designated by the file pattern 'apattern' are loaded. The triggers tree is accessed in the root directory 'adirectory'. The verbosity level, set by 'averbose', follows the GWOLLUM convention for verbosity.
| apattern | input file pattern | |
| adirectory | trigger ROOT directory | |
| averbose | verbosity level |
| ReadTriggers::~ReadTriggers | ( | void | ) | [virtual] |
Destructor of the ReadTriggers class.
| bool ReadTriggers::Clusterize | ( | void | ) |
Clusters triggers.
A clustering algorithm can be applied on triggers. The clustering is performed on the fly and all the cluster information is stored in memory.
One algorithm is implemented: triggers are clustered time-wise.
A trigger is defined by a peak time value and a duration (tend - tstart).
This clustering method can be described by the following logic:
'time'
A trigger can be represented by a time segment: |----||--------|
tstart tend
2 consecutive triggers are clustered if they verify one of the 2 following scenarios:
Scenario#1: overlapping triggers,
trigger#1 |---||---------|
trigger#2 |--------||--|
Scenario#2: if the distance inter-triggers dt < delta_t,
trigger#1 |---||---------|
trigger#2 |--------||--|
<----->
dt
In Scenario#2, 2 consecutive triggers are clustered if the time distance
between them is smaller than the delta_t parameter. This parameter is equal
to 100ms by default. It can be changed with the SetDeltaT() function.
The new cluster takes the characteristics of the loudest trigger of the cluster, i.e. the 'time', 'frequency', 'q', 'amplitude' and 'snr' values. The time and frequency boundaries variables are integrated over the full cluster. The new cluster status is 1 by default (see SetClusterStatus()).
| double ReadTriggers::GetClusterAmplitude | ( | const int | aclst | ) |
Returns the peak Amplitude of cluster number aclst.
0.0 is returned if this function fails.
| aclst | cluster number |
| double ReadTriggers::GetClusterBandWidth | ( | const int | aclst | ) |
Returns the bandwidth of cluster number aclst.
0.0 is returned if this function fails.
| aclst | cluster number |
| double ReadTriggers::GetClusterDuration | ( | const int | aclst | ) |
Returns the duration of cluster number aclst.
0.0 is returned if this function fails.
| aclst | cluster number |
| double ReadTriggers::GetClusterFrequency | ( | const int | aclst | ) |
Returns the peak frequency of cluster number aclst.
0.0 is returned if this function fails.
| aclst | cluster number |
| double ReadTriggers::GetClusterFrequencyEnd | ( | const int | aclst | ) |
Returns the ending frequency of cluster number aclst.
0.0 is returned if this function fails.
| aclst | cluster number |
| double ReadTriggers::GetClusterFrequencyStart | ( | const int | aclst | ) |
Returns the starting frequency of cluster number aclst.
0.0 is returned if this function fails.
| aclst | cluster number |
| double ReadTriggers::GetClusterMeanDuration | ( | void | ) | [inline] |
Returns the mean duration of clusters.
| int ReadTriggers::GetClusterNumber | ( | const double | atime | ) |
Returns the cluster number of cluster overlapping time atime.
-1 is returned if this function fails.
| atime | time input |
| double ReadTriggers::GetClusterQ | ( | const int | aclst | ) |
Returns the peak Q value of cluster number aclst.
0.0 is returned if this function fails.
| aclst | cluster number |
| int ReadTriggers::GetClusterSize | ( | const int | aclst | ) |
Returns the size of cluster number aclst.
0 is returned if this function fails.
| aclst | cluster number |
| double ReadTriggers::GetClusterSNR | ( | const int | aclst | ) |
Returns the peak SNR of cluster number aclst.
0.0 is returned if this function fails.
| aclst | cluster number |
| int ReadTriggers::GetClusterStatus | ( | const int | aclst | ) |
Returns the status value of cluster number aclst.
-100 is returned if this function fails.
| aclst | cluster number |
| double ReadTriggers::GetClusterTheta | ( | const int | aclst | ) |
Returns the theta value of cluster number aclst.
-100.0 is returned if this function fails.
| aclst | cluster number |
| double ReadTriggers::GetClusterTime | ( | const int | aclst | ) |
Returns the peak time of cluster number aclst.
0.0 is returned if this function fails.
| aclst | cluster number |
| double ReadTriggers::GetClusterTimeEnd | ( | const int | aclst | ) |
Returns the ending time of cluster number aclst.
0.0 is returned if this function fails.
| aclst | cluster number |
| double ReadTriggers::GetClusterTimeStart | ( | const int | aclst | ) |
Returns the starting time of cluster number aclst.
0.0 is returned if this function fails.
| aclst | cluster number |
| double ReadTriggers::GetDeltaT | ( | void | ) | [inline] |
Returns the clustering delta_t value.
| double ReadTriggers::GetFrequencyMax | ( | void | ) | [inline] |
Returns the maximum value of frequency in the trigger sample.
Returns 10000.0 if no trigger.
| double ReadTriggers::GetFrequencyMin | ( | void | ) | [inline] |
Returns the minimum value of frequency in the trigger sample.
Returns 1.0 if no trigger.
| int ReadTriggers::GetNcluster | ( | void | ) | [inline] |
Returns the number of clusters.
| int ReadTriggers::GetNCluster | ( | void | ) | [inline] |
Returns the number of clusters.
| int ReadTriggers::GetNtrig | ( | void | ) | [inline] |
Returns the number of triggers.
| int ReadTriggers::GetNTrig | ( | void | ) | [inline] |
Returns the number of triggers.
| int ReadTriggers::GetNTriggers | ( | void | ) | [inline] |
Returns the number of triggers.
| int ReadTriggers::GetNtriggers | ( | void | ) | [inline] |
Returns the number of triggers.
| double ReadTriggers::GetSNRMax | ( | void | ) | [inline] |
Returns the maximum value of SNR in the trigger sample.
Returns 10000.0 if no trigger.
| double ReadTriggers::GetSNRMin | ( | void | ) | [inline] |
Returns the minimum value of SNR in the trigger sample.
Returns 1.0 if no trigger.
| double ReadTriggers::GetTimeMax | ( | void | ) | [inline] |
Returns the maximum time value in the trigger sample.
Reimplemented from ReadTriggerSegments.
| double ReadTriggers::GetTimeMin | ( | void | ) | [inline] |
Returns the minimum time value in the trigger sample.
Reimplemented from ReadTriggerSegments.
| double ReadTriggers::GetTriggerAmplitude | ( | const int | atrig | ) |
Returns the amplitude of trigger number atrig.
0.0 is returned if this function fails.
| atrig | trigger number |
| double ReadTriggers::GetTriggerBandWidth | ( | const int | atrig | ) |
Returns the bandwidth of trigger number atrig.
0.0 is returned if this function fails.
| atrig | trigger number |
| double ReadTriggers::GetTriggerDuration | ( | const int | atrig | ) |
Returns the duration of trigger number atrig.
0.0 is returned if this function fails.
| atrig | trigger number |
| string ReadTriggers::GetTriggerFile | ( | const double | atime | ) |
Returns the path to the file containing trigger time atime.
"none" is returned if this function fails.
| atime | trigger time |
| string ReadTriggers::GetTriggerFile | ( | const int | atrig | ) |
Returns the path to the file containing trigger number atrig.
"none" is returned if this function fails.
| atrig | trigger number |
| double ReadTriggers::GetTriggerFrequency | ( | const int | atrig | ) |
Returns the frequency of trigger number atrig.
0.0 is returned if this function fails.
| atrig | trigger number |
| double ReadTriggers::GetTriggerFrequencyEnd | ( | const int | atrig | ) |
Returns the ending frequency of trigger number atrig.
0.0 is returned if this function fails.
| atrig | trigger number |
| double ReadTriggers::GetTriggerFrequencyStart | ( | const int | atrig | ) |
Returns the starting frequency of trigger number atrig.
0.0 is returned if this function fails.
| atrig | trigger number |
| double ReadTriggers::GetTriggerQ | ( | const int | atrig | ) |
Returns the Q value of trigger number atrig.
0.0 is returned if this function fails.
| atrig | trigger number |
| double ReadTriggers::GetTriggerSNR | ( | const int | atrig | ) |
Returns the SNR value of trigger number atrig.
0.0 is returned if this function fails.
| atrig | trigger number |
| double ReadTriggers::GetTriggerTime | ( | const int | atrig | ) |
Returns the time of trigger number atrig.
0.0 is returned if this function fails.
| atrig | trigger number |
| double ReadTriggers::GetTriggerTimeEnd | ( | const int | atrig | ) |
Returns the ending time of trigger number atrig.
0.0 is returned if this function fails.
| atrig | trigger number |
| double ReadTriggers::GetTriggerTimeStart | ( | const int | atrig | ) |
Returns the starting time of trigger number atrig.
0.0 is returned if this function fails.
| atrig | trigger number |
| bool ReadTriggers::SetClusterBranchStatus | ( | const char * | bname, | |
| bool | status = true | |||
| ) |
Modifies the branch status of the cluster tree.
This function allows to change the status of the cluster tree branches. See also TTree::SetBranchStatus( ). This function is particularly useful to speed up processes looping over clusters. The user should re-activate the branch before using any other class functions.
| bname | branch name | |
| status | new status |
| bool ReadTriggers::SetClusterSNRthr | ( | const double | asnrthr | ) |
Sets a SNR threshold for clustering.
Only clusters with a SNR greater than this threshold will be saved. This function should be called before calling the Clusterize() function.
| asnrthr | new SNR threshold |
| bool ReadTriggers::SetClusterStatus | ( | const int | aclst, | |
| const int | anewstatus | |||
| ) |
Sets a new cluster status value.
Clusters can be tagged with a status. By default this status is 1. This function allows to assign a new status value to cluster 'aclst'.
| aclst | cluster index | |
| anewstatus | new cluster status |
| bool ReadTriggers::SetDeltaT | ( | const double | adeltat | ) |
Sets a new clustering delta_t.
Sets a new delta_t value for the time-clustering. The value should be given in seconds.
| adeltat | new delta_t value in seconds |
| bool ReadTriggers::SetNewPattern | ( | const string | apattern | ) |
Loads new trigger files.
This function resets the ReadTriggers class to introduce a new list of files given by 'apattern'.
| apattern | new input file pattern |
Reimplemented from ReadTriggerMetaData.
| bool ReadTriggers::SetTriggerBranchStatus | ( | const char * | bname, | |
| bool | status = true | |||
| ) |
Modifies the branch status of the triggers tree.
This function allows to change the status of the triggers tree branches. See also TTree::SetBranchStatus( ). This function is particularly useful to speed up processes looping over triggers. The user should re-activate the branch before using any other class functions.
| bname | branch name | |
| status | new status |
| bool ReadTriggers::WriteClusters | ( | TFile * | atfile, | |
| const string | adirectory = "" | |||
| ) |
Writes clusters in a ROOT file.
Clusters are saved in a ROOT file following the GWOLLUM convention for triggers. The segment tree is saved as well. Original metadata are not saved.
| atfile | ROOT file where to save the clusters | |
| adirectory | TDirectory where to save the clusters |
double ReadTriggers::Camp [protected] |
cluster peak Amplitude (TTree)
double ReadTriggers::Cdelta_t [protected] |
time clustering delta_t (s)
double ReadTriggers::Cfend [protected] |
cluster peak frequency end (TTree)
Long64_t ReadTriggers::Cfirstentry [protected] |
cluster first trigger entry (TTree)
double ReadTriggers::Cfreq [protected] |
cluster peak frequency (TTree)
double ReadTriggers::Cfstart [protected] |
cluster peak frequency start (TTree)
double ReadTriggers::cl_snr_thr [protected] |
SNR threshold for clustering.
int* ReadTriggers::cl_status [protected] |
cluster status
double ReadTriggers::Cmeandur [protected] |
cluster mean duration
double ReadTriggers::Cq [protected] |
cluster peak Q (TTree)
Long64_t ReadTriggers::Csize [protected] |
cluster size (TTree)
double ReadTriggers::Csnr [protected] |
cluster peak SNR (TTree)
double ReadTriggers::Ctend [protected] |
cluster peak time end (TTree)
double ReadTriggers::Ctime [protected] |
cluster peak time (TTree)
TTree* ReadTriggers::Ctree [protected] |
cluster parameter tree
double ReadTriggers::Ctstart [protected] |
cluster peak time start (TTree)
double ReadTriggers::fFreqMax [protected] |
max peak frequency
double ReadTriggers::fFreqMin [protected] |
min peak frequency
double ReadTriggers::fSNRMax [protected] |
max peak snr
double ReadTriggers::fSNRMin [protected] |
min peak snr
Long64_t* ReadTriggers::offsets [protected] |
tree offsets - DO NOT DELETE
double ReadTriggers::Tamp [protected] |
trigger peak Amplitude (TTree)
double ReadTriggers::Tfend [protected] |
trigger peak frequency end (TTree)
double ReadTriggers::Tfreq [protected] |
trigger peak frequency (TTree)
double ReadTriggers::Tfstart [protected] |
trigger peak frequency start (TTree)
double ReadTriggers::Tq [protected] |
trigger peak Q (TTree)
double ReadTriggers::Tsnr [protected] |
trigger peak SNR (TTree)
double ReadTriggers::Ttend [protected] |
trigger peak time end (TTree)
double ReadTriggers::Ttime [protected] |
trigger peak time (TTree)
Chain* ReadTriggers::Ttree [protected] |
trigger parameter trees
double ReadTriggers::Ttstart [protected] |
trigger peak time start (TTree)
1.6.1
